JVC SR-VS20E User Manual

5-23
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
BK1 LP40077-001A BRACKET(BOARD)
CN511 QGG2503K2-30 HEADER PIN,(1-30)MAIN
CN512 QGF1209F2-14 FFC/FPC CONNE,(1-14)TERMINAL
******************************
DV PRE/REC MDA BOARD ASSEMBLY <16>
PW2 LPA10117-01C2 DV PRE/REC MDA BOARD ASSY
IC5001 JCY0132 IC
IC5002 TC7SH00FU IC(DIGITAL)
IC5501 BA6865KV IC
IC5502 BA6417F IC
Q5501 DTA114EU TRANSISTOR
Q5502 2SB1302/ST/-X TRANSISTOR
Q5503 2SB1302/ST/-X TRANSISTOR
Q5504 2SB1302/ST/-X TRANSISTOR
Q5505 2SC4097/QR/-X TRANSISTOR
D5502 DAP222 DIODE
D5503 DAP222 DIODE
D5504 DAP222 DIODE
R5003 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5004 NRSA63J-471X MG RESISTOR 470Ø,1/16W
R5007 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R5014 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R5018 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R5019 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5020 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5021 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R5023 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R5026 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R5035 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R5057 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R5058 NRSA63J-392X MG RESISTOR 3.9kØ,1/16W
R5101 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5102 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5111 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5112 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5114 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5115 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5117 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5118 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5119 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5121 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5501 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R5502 NRSA63J-124X MG RESISTOR 120kØ,1/16W
R5503 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R5504 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R5505 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R5506 NRV142F-R22X CMF RESISTOR 0.22Ø,1/4W
R5509 NRS12BK-R68W MG RESISTOR 0.68Ø,1/2W
R5510 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R5511 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R5512 NRSA63J-274X MG RESISTOR 270kØ,1/16W
R5513 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W
R5514 NRSA63J-154X MG RESISTOR 150kØ,1/16W
R5515 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R5516 NRSA63J-202X MG RESISTOR 2kØ,1/16W
R5517 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R5518 NRSA63J-203X MG RESISTOR 20kØ,1/16W
R5519 NRSA63J-393X MG RESISTOR 39kØ,1/16W
R5520 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R5522 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R5523 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R5525 NRSA63J-511X MG RESISTOR 510Ø,1/16W
R5526 NRSA63J-511X MG RESISTOR 510Ø,1/16W
R5527 NRSA63J-511X MG RESISTOR 510Ø,1/16W
R5528 NRSA63J-511X MG RESISTOR 510Ø,1/16W
R5529 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R5530 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5531 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5533 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5534 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5536 NRSA63J-823X MG RESISTOR 82kØ,1/16W
R5537 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R5543 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R5544 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R5545 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R5546 NRSA63J-393X MG RESISTOR 39kØ,1/16W
R5547 NRSA02J-1R8X MG RESISTOR 1.8Ø,1/10W
R5548 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R5549 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R5550 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R5551 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5552 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5553 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5554 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5555 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5556 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5557 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5558 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5559 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5560 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5561 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
C5002 NCB31CK-104X CAPACITOR 0.1µF,16V
C5003 NCB31CK-104X CAPACITOR 0.1µF,16V
C5004 NCB31CK-223X CAPACITOR 0.022µF,16V
C5005 NCB31CK-473X CAPACITOR 0.047µF,16V
C5006 NCB31CK-104X CAPACITOR 0.1µF,16V
C5007 NCB31CK-104X CAPACITOR 0.1µF,16V
C5008 NCB31CK-104X CAPACITOR 0.1µF,16V
C5009 NEA70JM-226X E CAPACITOR 22µF,6.3V
C5010 NCB31CK-104X CAPACITOR 0.1µF,16V
C5011 NCB31CK-104X CAPACITOR 0.1µF,16V
C5012 NEA70JM-226X E CAPACITOR 22µF,6.3V
C5034 NCB31CK-104X CAPACITOR 0.1µF,16V
C5035 NCB31CK-104X CAPACITOR 0.1µF,16V
C5036 NCB31CK-104X CAPACITOR 0.1µF,16V
C5037 NEA70JM-226X E CAPACITOR 22µF,6.3V
C5039 NCB31CK-104X CAPACITOR 0.1µF,16V
C5045 NCB31CK-473X CAPACITOR 0.047µF,16V
C5046 NCB31CK-473X CAPACITOR 0.047µF,16V
C5047 NCB31CK-473X CAPACITOR 0.047µF,16V
C5048 NEA70JM-226X E CAPACITOR 22µF,6.3V
C5049 NCB31CK-104X CAPACITOR 0.1µF,16V
C5050 NCB31CK-104X CAPACITOR 0.1µF,16V
C5051 NCB31CK-104X CAPACITOR 0.1µF,16V
C5052 NDC31HJ-102X CAPACITOR 0.001µF,50V
C5053 NCB31CK-104X CAPACITOR 0.1µF,16V
C5055 NCB31CK-104X CAPACITOR 0.1µF,16V
C5056 NCB31CK-104X CAPACITOR 0.1µF,16V
C5058 NCB20JM-475X CAPACITOR 4.7µF,6.3V
C5060 NCB31CK-104X CAPACITOR 0.1µF,16V
