<Note 1> : If the wires for the cassette housing motor are
connected to the circuit board, remove them be-
fore disassembly.
<Note 2> : If wires are connected to the circuit board, re-
move them before disassembly.
<Note 3> : Be careful not to damage the drum assembly
when removing it.
<Note 4> : The bracket (DV) may come in the way of re-
moval of screw (7). Be sure to remove the
bracket before proceeding to the screw removal.
2.13 DISASSEMBLY/ASSEMBLY
1.
A Cassette Housing Assembly/ B Mechanism Assembly
Fig. 2-13-1
1
(
S1
)
A
2
(
S1
)
(
L2
)
(
L4
)
(
L5
)
(
L1
)
(
L3
)
B
<Note1>
Fig. 2-13-2
5
(
S2
)
1
2
3
(
S2
)
4
(
S2
)
7
(
S2
)
6
(
S2
)
9
(
S2
)
8
(
S2
)
<Note2>
<Note2>
<Note4>
<Note3>
2. 1 Drum assembly / 2 Motor bracket assembly
