5-9
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
C5213 QETN1AM-227 E CAPACITOR 220µF,10V
C5301 QFLC1HJ-103Z F CAPACITOR 0.01µF,50V
C5302 QFLC1HJ-473Z F CAPACITOR 0.047µF,50V
C5303 QFLC1HJ-333Z F CAPACITOR 0.033µF,50V
C5304 QETN1EM-476 E CAPACITOR 47µF,25V
C5305 QFLC1HJ-103Z F CAPACITOR 0.01µF,50V
L5201 PELN1184 COIL 33µH
L5202 PU60944-330K COIL 33µH
L5203 PELN1184 COIL 33µH
L5205 PELN1184 COIL 33µH
K5101 QQR0678-001Z FERRITE BEAD
! PC5101 PC123F2 PH COUPLER
! T5001 QQS0092-001 SW TRANSFORMER
HS1 LP40515-001B HEAT SINK,D5206
ST2 PU59391 STYLE PIN
OT1 QYTDST3008Z SCREW,D5206
FC5001 QNG0006-001Z FUSE CLIP,F5001
FC5002 QNG0006-001Z FUSE CLIP,F5001
! LF5001 PELN1204-01-01 LINE FILTER
! LF5002 QQR1031-001 LINE FILTER
! CN5001 QGA7901C3-02 CONNECTOR,(1-2)AC IN
CN5201 QGF1208C1-19 FPC CONNECTOR,(1-19)REG
! CP5301 ICP-N25 CIRCUIT PROTECTOR
! F5001 QMF51E2-2R0J1 FUSE T2.0A,AC250V
******************************
REGULATOR BOARD ASSEMBLY <02>
PW2 LPA10119-01D2 REG BOARD ASSY
IC5321 PQ15RW11 IC
Q5321 2SD2528/QP/ TRANSISTOR
Q5322 2SD1819A/RS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
or 2SC4081/RS/-X TRANSISTOR
Q5323 2SA933AS/RS/-T TRANSISTOR
or 2SA1267/YG/-T TRANSISTOR
Q5324 DTC114EU TRANSISTOR
or PDTC114EU TRANSISTOR
or UN5211 TRANSISTOR
or RN1302 TRANSISTOR
Q5326 2SD2375/QP/ TRANSISTOR
Q5327 2SD1819A/RS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
or 2SC4081/RS/-X TRANSISTOR
Q5328 2SD1302/ST/-T TRANSISTOR
or 2SD1450/ST/-T TRANSISTOR
Q5329 DTA114EU TRANSISTOR
or PDTA114EU TRANSISTOR
or UN5111 TRANSISTOR
or RN2302 TRANSISTOR
Q5330 2SD2144S/UV/-T TRANSISTOR
Q5331 2SB1068/KU/-T TRANSISTOR
Q5332 DTC114EU TRANSISTOR
or PDTC114EU TRANSISTOR
or UN5211 TRANSISTOR
or RN1302 TRANSISTOR
Q5333 2SD1450/ST/-T TRANSISTOR
or 2SD1302/ST/-T TRANSISTOR
Q5334 DTA114EU TRANSISTOR
or RN2302 TRANSISTOR
or UN5111 TRANSISTOR
or PDTA114EU TRANSISTOR
Q5335 2SB1256 TRANSISTOR
Q5336 DTC114TU TRANSISTOR
or UN5215 TRANSISTOR
Q5337 2SB1239 TRANSISTOR
Q5339 2SD2144S/UV/-T TRANSISTOR
Q5340 DTA114EU TRANSISTOR
or PDTA114EU TRANSISTOR
or UN5111 TRANSISTOR
or RN2302 TRANSISTOR
Q5341 DTC114EU TRANSISTOR
or PDTC114EU TRANSISTOR
or UN5211 TRANSISTOR
or RN1302 TRANSISTOR
D5322 1SS133 DIODE
or 1SS270A DIODE
D5323 11ES2 DIODE
or ERA15-02-T2 DIODE
or 1A3G DIODE
D5324 11ES2 DIODE
or 1A3G DIODE
or ERA15-02-T2 DIODE
D5325 RD5.1JS/B2/-T2 ZENER DIODE
or MA4051N/M/-T2 ZENER DIODE
D5326 1SS133 DIODE
or 1SS270A DIODE
D5327 RD5.1JS/B2/-T2 ZENER DIODE
or MA4051N/M/-T2 ZENER DIODE
D5328 1SS133 DIODE
or 1SS270A DIODE
D5329 1SS133 DIODE
or 1SS270A DIODE
D5330 1SS133 DIODE
or 1SS270A DIODE
D5331 1SS133 DIODE
or 1SS270A DIODE
D5332 11ES2 DIODE
or ERA15-02-T2 DIODE
or 1A3G DIODE
D5333 1SS133 DIODE
or 1SS270A DIODE
D5334 11ES2 DIODE
or 1A3G DIODE
or ERA15-02-T2 DIODE
D5336 MTZJ12A ZENER DIODE
or RD12ES/B1/-T2 ZENER DIODE
R5322 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5323 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5324 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5325 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5326 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5327 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5328 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5329 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5330 NRSA02J-471X MG RESISTOR 470Ø,1/10W
