1-12
Fig.
Connection
Type
No.
Symbol
Connected point ←→ Connected point
Pin No.
(FPC/
WIRE)
1 WR1 MAIN CN7507 ←→ JACK CN7002 16 FPC
2 WR2 MAIN CN3011 ←→ DISPLAY CN7001 18 FPC
3 WR3 REGULATOR CN5301 ←→ SW REG CN5201 19 FPC
4 WR4 REGULATOR CN5322 ←→ MAIN CN7508 13 FPC
5 WR5 REGULATOR CN5321 ←→ MAIN CN7509 15 FPC
6 WR6 REGULATOR CN5325 ←→ FAN MOTOR – 2 WIRE
7 WR7 REGULATOR CN5324 ←→ PRE/REC MDA CN5501 5 WIRE
8 WR8 REGULATOR CN5323 ←→ DV MAIN CN1001 10 WIRE
9 WR9 DRUM MOTOR CON1 ←→ MAIN CN3001 5 FPC
10 WR10 MAIN CN1 ←→ UPPER DRUM – 13 FPC
11 WR11 A/C HEAD CN1 ←→ MAIN CN2001 7 FPC
12 WR12 MAIN CN3014 ←→ DV MAIN CN1002 6 FPC
13 WR13 MAIN CN703 ←→ DV MAIN CN3501 6 WIRE
14 WR14 MAIN CN2601 ←→ DV MAIN CN3701 8 FPC
15 WR15 DV MAIN CN1502 ←→ SENSOR – 15 FPC
16 WR16 PRE/REC MDA CN5002 ←→ DV MAIN CN2001 26 FPC
17 WR17 PRE/REC MDA CN5506 ←→ DV MAIN CN1501 20 FPC
18 WR18 PRE/REC MDA CN5507 ←→ DV HOUSING MOTOR – 4 WIRE
19 WR19 PRE/REC MDA CN5502 ←→ DV LOADING MOTOR – 2 WIRE
20 WR20 PRE/REC MDA CN5505 ←→ DV ENCODER – 4 WIRE
21 WR21 PRE/REC MDA CN5503 ←→ DV DRUM MOTOR – 11 FPC
22 WR22 PRE/REC MDA CN5504 ←→ DV CAPSTAN MOTOR – 18 FPC
23 WR23 PRE/REC MDA CN5001 ←→ DV VIDEO HEAD – 10 FPC
24 – MAIN CN7506 ←→ S-SUB CN512 14 FPC
–– DV MAIN CN1101 ←→ Jig CONN. CABLE – 26 –
Table 1-10-1 Connection
To Next Page
