5-21
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
R7172 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R7173 NRSA02J-3R3X MG RESISTOR 3.3kØ,1/10W
C7101 NCB21HK-103X CAPACITOR 0.01µF,50V
C7102 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C7103 QEKJ1CM-476 E CAPACITOR 47µF,16V
C7104 NCB21HK-103X CAPACITOR 0.01µF,50V
C7105 NCB21HK-103X CAPACITOR 0.01µF,50V
C7106 NCB21EK-104X CAPACITOR 0.1µF,25V
C7107 NCB21HK-103X CAPACITOR 0.01µF,50V
C7108 NCB21HK-103X CAPACITOR 0.01µF,50V
C7109 QEKJ1CM-106 E CAPACITOR 10µF,16V
C7110 NDC21HJ-101X CAPACITOR 100pF,50V
C7112 QEKJ1CM-106 E CAPACITOR 10µF,16V
C7113 NCB21HK-103X CAPACITOR 0.01µF,50V
C7114 NDC21HJ-101X CAPACITOR 100pF,50V
C7115 QEKJ1HM-105 E CAPACITOR 1µF,50V
C7116 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C7117 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C7118 QEKJ0JM-107 E CAPACITOR 100µF,6.3V
C7119 NCB21HK-103X CAPACITOR 0.01µF,50V
C7120 QEPF1HM-474 NP E CAPACITOR 0.47µF,50V
C7121 NDC21HJ-270X CAPACITOR 27pF,50V
C7122 NCB21HK-103X CAPACITOR 0.01µF,50V
C7123 NCB21HK-103X CAPACITOR 0.01µF,50V
C7124 NCB21HK-103X CAPACITOR 0.01µF,50V
C7125 QEKJ1CM-476 E CAPACITOR 47µF,16V
C7126 NCB21HK-103X CAPACITOR 0.01µF,50V
C7127 NDC21HJ-330X CAPACITOR 33pF,50V
C7129 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C7130 NCB21HK-681X CAPACITOR 680pF,50V
C7131 NCB21HK-102X CAPACITOR 0.001µF,50V
C7132 NCB21HK-681X CAPACITOR 680pF,50V
C7133 NCB21HK-102X CAPACITOR 0.001µF,50V
C7138 QEKJ1CM-107 E CAPACITOR 100µF,16V
C7139 QEKJ1CM-107 E CAPACITOR 100µF,16V
C7140 NCB21EK-104X CAPACITOR 0.1µF,25V
C7142 NCB21EK-104X CAPACITOR 0.1µF,25V
C7143 NCB21EK-104X CAPACITOR 0.1µF,25V
C7145 NCB21EK-104X CAPACITOR 0.1µF,25V
C7146 NDC21HJ-330X CAPACITOR 33pF,50V
C7147 NCB21EK-104X CAPACITOR 0.1µF,25V
C7148 NCB21EK-104X CAPACITOR 0.1µF,25V
C7150 NCB21HK-103X CAPACITOR 0.01µF,50V
C7151 QEKJ1CM-106 E CAPACITOR 10µF,16V
C7152 QEKJ1CM-106 E CAPACITOR 10µF,16V
C7153 QEKJ1CM-106 E CAPACITOR 10µF,16V
C7154 NCB21CK-105X CAPACITOR 1µF,16V
C7155 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C7156 NCB21HK-681X CAPACITOR 680pF,50V
C7158 NCB21HK-681X CAPACITOR 680pF,50V
C7159 NCB21HK-102X CAPACITOR 0.001µF,50V
C7166 NCB21HK-102X CAPACITOR 0.001µF,50V
C7167 NCB21HK-102X CAPACITOR 0.001µF,50V
C7168 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C7169 NCB21HK-103X CAPACITOR 0.01µF,50V
C7170 NCB21HK-102X CAPACITOR 0.001µF,50V
L7101 QQL29BJ-4R7Z COIL 4.7µH
L7102 QQL29BJ-4R7Z COIL 4.7µH
L7103 QQL29BJ-4R7Z COIL 4.7µH
L7106 QQL071J-4R7Y COIL 4.7µH
L7107 QQL071J-4R7Y COIL 4.7µH
L7108 QQL071J-4R7Y COIL 4.7µH
L7109 QQL071J-4R7Y COIL 4.7µH
L7113 QQL071J-1R0Y COIL 1µH
L7115 QQL29BK-1R0Z COIL 1µH
L7117 QQL071J-4R7Y COIL 4.7µH
L7118 QQL071J-4R7Y COIL 4.7µH
L7119 QQL071J-4R7Y COIL 4.7µH
L7120 QQL071J-4R7Y COIL 4.7µH
L7121 QQL071J-4R7Y COIL 4.7µH
L7122 QQL071J-4R7Y COIL 4.7µH
ET1 QNZ0431-001Z EARTH TERMINAL
J7101 QND0009-001 S JACK,S_OUT
J7102 QNZ0418-001 21P CONNECTOR,AV1
J7103 PU60659 MINI JACK,SAT_CTL
J7104 QNZ0418-001 21P CONNECTOR,AV2
J7105 QNN0295-002 PIN JACK,A.OUT(L/R)
CN7101 QGB2024J1-15S CONNECTOR,(1-15)MAIN
CN7102 QGB2024J1-05S CONNECTOR,(1-5)MAIN
CN7103 QGB2024J1-14S CONNECTIR,(1-14)MAIN
CN7104 QGB2024J1-11S CONNECTOR,(1-11)MAIN
******************************
AUDIO CONTROL HEAD BOARD ASSEMBLY <12>
PW1 LPA10010-01A1 A/C HEAD BOARD ASSY
CN1 QGF1208F1-07 FPC CONNECTOR
******************************
DEMOD BOARD ASSEMBLY <14>
PW1 LPA10094-01C DEMOD BOARD ASSY
IC6701 MSP34VCDT IC
or MSP3417D IC
Q6701 2SC3936/BC/-X TRANSISTOR
D6701 1SS133 DIODE
or 1N4148M DIODE
R6701 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W
R6702 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W
R6703 NRSA02J-470X MG RESISTOR 47Ø,1/10W
R6704 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6705 NRSA02J-271X MG RESISTOR 270Ø,1/10W
R6706 NRSA02J-151X MG RESISTOR 150Ø,1/10W
R6707 NRSA02J-220X MG RESISTOR 22Ø,1/10W
R6708 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R6709 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R6710 NRSA02J-100X MG RESISTOR 10Ø,1/10W
R6711 NRSA02J-684X MG RESISTOR 680kØ,1/10W
R6712 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6714 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6716 NRSA02J-470X MG RESISTOR 47Ø,1/10W
R6719 QRE141J-103Y RESISTOR 10kØ,1/4W
R6720 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
