# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-18
L28 QQL071J-680Y COIL 68µH
L401 QQL071J-150Y COIL 15µH
L701 QQL29BJ-4R7Z COIL 4.7µH
L702 QQL29BJ-4R7Z COIL 4.7µH
L714 QQL29BJ-4R7Z COIL 4.7µH
L715 QQL29BJ-4R7Z COIL 4.7µH
L2001 QQL29BJ-100Z COIL 10µH
L2251 QQL29BJ-100Z COIL 10µH
L2252 QQL29BJ-151Z COIL 150µH
L3011 QRE141J-0R0Y RESISTOR 0Ø,1/4W
L3012 QRE141J-0R0Y RESISTOR 0Ø,1/4W
L3301 QQL231J-100Y COIL 10µH
L6001 QQL29BJ-100Z COIL 10µH
L6002 QQL29BJ-100Z COIL 10µH
L6005 QQL29BJ-100Z COIL 10µH
L7501 QQL29BJ-101Z COIL 100µH
CF3301 QAX0227-001Z RESONATOR
X1 QAX0576-001 CRYSTAL RESONATOR
X3001 QAX0445-001 CRYSTAL RESONATOR,SR-VS20E
QAX0444-001 CRYSTAL RESONATOR,SR-VS20EK
X3002 QAX0527-001 CRYSTAL RESONATOR
S3001 QSW0602-004 PUSH SWITCH,REC SAFETY
S3002 QSW0695-001 PUSH SWITCH,S CASS SW
K2001 NQL092M-47NX COIL
K2002 NQL092M-47NX COIL
K2251 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K2252 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K2253 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K6080 NQR0200-003X FERRITE BEAD
PC3001 GP3S123 IC(PHOTO SENSOR)
PC3002 GP3S123 IC(PHOTO SENSOR)
T2051 PELN0860 OSC TRANSFORMER
T2052 PELN0861 OSC TRANSFORMER
TU6001 QAU0151-001 TUNER
SD1 LP30644-001A SHIELD CASE(PRE)
OT1 LP40229-002A PLATE
W855 NRSA02J-101X MG RESISTOR 100Ø,1/10W
WR100 QUQ112-1414CG FFC WIRE,CN7506
CN1 QGF1028C1-13 FPC CONNECTOR,(1-13)U.DRUM
CN703 QGA2001C1-06 CONNECTOR,(1-6)DV MAIN
CN2001 QGF1207C1-07 FPC CONNECTOR,(1-7)A/C HEAD
CN2002 QGB2532J1-02 CONNECTOR,(1-2)FE HEAD
CN2601 QGF1016C3-08 FFC/FPC CONNECTOR,(1-8)DV AUDIO
CN3001 QGF1207C1-05 FPC CONNECTOR,(1-5)DRUM MDA
CN3002 QGB2532J1-02 CONNECTOR,(1-2)LOADING MOTOR
CN3003 QGB2015M2-08 CONNECTOR,(1-8)CAPSTAN MOTOR
CN3004 QGB2534J2-04 CONNECTOR,(1-4)ROTARY ENCODER
CN3011 QGF1209F2-18 FFC/FPC CONNECTOR,(1-18)SW/DISPLAY
CN3014 QGF1016C3-06 FFC/FPC CONNECTOR,(1-6)DV MAIN
CN7501 QGB2024K1-15S CONNECTOR,(1-15)TERMINAL
CN7502 QGB2024K1-05S CONNECTOR,(1-5)TERMINAL
CN7503 QGB2024K1-14S CONNECTOR,(1-14)TERMINAL
CN7504 QGB2024K1-11S CONNECTOR,(1-11)TERMINAL
CN7506 QGF1207C1-14 FPC CONNECTOR,(1-14)S-SUB
CN7507 QGF1209F2-16 FFC/FPC CONNECTOR,(1-16)JACK
CN7508 QGF1207C1-13 FPC CONNECTOR,(1-13)REG
CN7509 QGF1207C1-15 FPC CONNECTOR,(1-15)REG
! CP3002 ICP-N15 CIRCUIT PROTECTOR
! CP3003 ICP-N25 CIRCUIT PROTECTOR
! CP3004 ICP-N15 CIRCUIT PROTECTOR
! CP4001 ICP-N25 CIRCUIT PROTECTOR
******************************
3D DIGITAL/2M BOARD ASSEMBLY <05>
PW1 LPA10105-03A 3D DIGITAL/2M BOARD ASSY
IC1401 JCP8026 IC
Q1401 2SC1317/RS/-T TRANSISTOR
Q1402 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1403 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1404 DTC144WU TRANSISTOR
or RN1309 TRANSISTOR
or UN521E TRANSISTOR
Q1406 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1407 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1408 2SC4081/S/-X TRANSISTOR
Q1410 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
Q1412 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
Q1413 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1414 DTC144WU TRANSISTOR
or RN1309 TRANSISTOR
or UN521E TRANSISTOR
Q1417 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
Q1418 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q1419 DTC124TU TRANSISTOR
Q1420 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
D1401 RD4.3ES/B2/-T2 ZENER DIODE
or MTZJ4.3B ZENER DIODE
D1402 1SS133 DIODE
or 1N4148M DIODE
R1401 NRSA02J-181X MG RESISTOR 180Ø,1/10W
R1402 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R1404 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W
R1406 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R1407 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W
R1408 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R1410 NRSA02J-391X MG RESISTOR 390Ø,1/10W
R1411 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W
R1413 NRSA02J-331X MG RESISTOR 330Ø,1/10W
R1414 NRSA02J-821X MG RESISTOR 820Ø,1/10W
R1415 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R1416 NRSA02J-104X MG RESISTOR 100kØ,1/10W
R1417 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R1418 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R1421 NRSA02J-391X MG RESISTOR 390Ø,1/10W
R1426 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R1427 NRSA02J-333X MG RESISTOR 33kØ,1/10W
R1428 NRSA02J-393X MG RESISTOR 39kØ,1/10W
R1429 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W
R1430 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
