5-25
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
R878 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R879 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R880 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R881 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R882 NRSA02J-184X MG RESISTOR 180kØ,1/10W
R883 NRSA02J-822X MG RESISTOR 8.2kØ,1/10W
R884 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W
R885 NRSA02J-153X MG RESISTOR 15kØ,1/10W
R886 NRSA02J-681X MG RESISTOR 680Ø,1/10W
R887 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R888 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R889 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R891 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C851 QEKJ0JM-337 E CAPACITOR 330µF,6.3V
C852 NCB21EK-224X CAPACITOR 0.22µF,25V
C853 NCB21CK-105X CAPACITOR 1µF,16V
C856 NCB21CK-105X CAPACITOR 1µF,16V
C857 NDC21HJ-560X CAPACITOR 56pF,50V
C858 NCB21CK-474X CAPACITOR 0.47µF,16V
C860 NCB21HK-103X CAPACITOR 0.01µF,50V
C861 NDC21HJ-150X CAPACITOR 15pF,50V
C862 NDC21HJ-470X CAPACITOR 47pF,50V
C863 NDC21HJ-101X CAPACITOR 100pF,50V
C865 NDC21HJ-100X CAPACITOR 10pF,50V
C867 NDC21HJ-330X CAPACITOR 33pF,50V
C868 NDC21HJ-330X CAPACITOR 33pF,50V
C870 NDC21HJ-101X CAPACITOR 100pF,50V
C871 NDC21HJ-101X CAPACITOR 100pF,50V
C872 NCB21EK-104X CAPACITOR 0.1µF,25V
C873 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C874 NCB21EK-224X CAPACITOR 0.22µF,25V
C875 NCB21EK-224X CAPACITOR 0.22µF,25V
C876 QEKJ0JM-227 E CAPACITOR 220µF,6.3V
C877 QEKJ1CM-476 E CAPACITOR 47µF,16V
C878 NCB21HK-103X CAPACITOR 0.01µF,50V
C879 NCB21EK-104X CAPACITOR 0.1µF,25V
C881 NCB21HK-471X CAPACITOR 470pF,50V
C882 NCB21HK-223X CAPACITOR 0.022µF,50V
C883 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C884 NCB21EK-104X CAPACITOR 0.1µF,25V
C885 NCB21EK-104X CAPACITOR 0.1µF,25V
C886 NCB21EK-104X CAPACITOR 0.1µF,25V
L851 QQL01BK-1R0Z COIL 1µH
L852 QQL071J-220Y COIL 22µH
L853 QQL29BJ-100Z COIL 10µH
L855 QQL071J-270Y COIL 27µH
L856 QQL071J-820Y COIL 82µH
L857 QQL071J-330Y COIL 33µH
L858 QQL37CJ-220Z COIL 22µH
L859 QQL29BJ-4R7Z COIL 4.7µH
T851 PELN0806 LC TRAP
BK1 LP40077-001A BRACKET(BOARD)
CN851 QGG2502K1-20 HEADER PIN
******************************
EJECT SW BOARD ASSEMBLY <27>
PW5 LPA10126-01C5 EJECT SW BOARD ASSY
S7011 QSW0456-002Z TACT SWITCH,VHS EJECT
FW7005 QUM022-15A4A4 PARA RIBON WIRE
******************************
SW/DISPLAY BOARD ASSEMBLY <28>
PW1 LPA10126-01C1 SW/DISPLAY BOARD ASSY
IC7001 M35500BGP IC
or M35500AGP IC
IC7002 PNA4652M00XB IR DETECT UNIT
or GP1U281X IR DETECT UNIT
D7002 RD9.1ES/B2/-T2 ZENER DIODE
or UZ9.1BSB ZENER DIODE
or MTZJ9.1B ZENER DIODE
D7004 1SS133 DIODE
or 1N4148M DIODE
D7005 1SS133 DIODE
or 1N4148M DIODE
D7006 1SS133 DIODE
or 1N4148M DIODE
D7009 SLR-342DU3F LE DIODE
D7010 SLR-342MG3F LE DIODE
D7011 SLR-342VR3F LE DIODE
D7013 SLR-342MG3F LE DIODE
D7014 SLR-342VR3F LE DIODE
D7015 SLR-342MG3F LE DIODE
D7016 SLR-342MG3F LE DIODE
R7001 QRE141J-471Y RESISTOR 470Ø,1/4W
R7002 QRE141J-471Y RESISTOR 470Ø,1/4W
R7003 QRE141J-471Y RESISTOR 470Ø,1/4W
R7004 QRE141J-471Y RESISTOR 470Ø,1/4W
R7006 QRE141J-103Y RESISTOR 10kØ,1/4W
R7007 QRE141J-103Y RESISTOR 10kØ,1/4W
R7008 QRE141J-103Y RESISTOR 10kØ,1/4W
R7013 QRE141J-103Y RESISTOR 10kØ,1/4W
R7020 QRE141J-103Y RESISTOR 10kØ,1/4W
R7021 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R7022 QRE141J-182Y RESISTOR 1.8kØ,1/4W
R7023 QRE141J-222Y RESISTOR 2.2kØ,1/4W
R7024 QRE141J-272Y RESISTOR 2.7kØ,1/4W
R7025 QRE141J-472Y RESISTOR 4.7kØ,1/4W
R7026 QRE141J-682Y RESISTOR 6.8kØ,1/4W
R7027 QRE141J-153Y RESISTOR 15kØ,1/4W
R7028 QRE141J-393Y RESISTOR 39kØ,1/4W
R7030 QRE141J-103Y RESISTOR 10kØ,1/4W
R7031 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R7032 QRE141J-182Y RESISTOR 1.8kØ,1/4W
R7033 QRE141J-222Y RESISTOR 2.2kØ,1/4W
R7034 QRE141J-272Y RESISTOR 2.7kØ,1/4W
R7035 QRE141J-472Y RESISTOR 4.7kØ,1/4W
R7036 QRE141J-682Y RESISTOR 6.8kØ,1/4W
