# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-10
R5331 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R5332 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5333 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5336 NRVA02D-472X CMF RESISTOR 4.7kØ,1/10W
R5337 NRVA02D-102X CMF RESISTOR 1kØ,1/10W
R5338 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5339 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5340 QRL01DJ-101X OMF RESISTOR 100Ø,1W
R5341 NRSA02J-511X MG RESISTOR 510Ø,1/10W
R5342 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5343 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R5344 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R5345 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R5346 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R5347 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R5348 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R5351 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R5352 NRSA02J-102X MG RESISTOR 1kØ,1/10W
C5321 QETN1AM-107 E CAPACITOR 100µF,10V
C5322 QETN1HM-106 E CAPACITOR 10µF,50V
C5323 QETN1CM-107 E CAPACITOR 100µF,16V
C5324 QFLC1HJ-102Z F CAPACITOR 0.001µF,50V
C5325 QFLC1HJ-102Z F CAPACITOR 0.001µF,50V
C5326 QETN1AM-107 E CAPACITOR 100µF,10V
C5329 NCB21HK-103X CAPACITOR 0.01µF,50V
C5330 QETN1AM-107 E CAPACITOR 100µF,10V
C5331 QETN1AM-107 E CAPACITOR 100µF,10V
C5332 QETN1CM-226 E CAPACITOR 22µF,16V
C5333 QETN1AM-107 E CAPACITOR 100µF,10V
C5334 QETN1CM-227 E CAPACITOR 220µF,16V
C5335 QETN1CM-107 E CAPACITOR 100µF,16V
HS1 LP40090-001A HEAT SINK,Q5321
OT1 QYTDST3006Z SCREW,Q5321
CN5301 QGF1208C1-19 FPC CONNECTOR,(1-19)SW/REG
CN5321 QGF1208F1-15 FPC CONNECTOR,(1-15)MAIN
CN5322 QGF1208F1-13 FPC CONNECTOR,(1-13)MAIN
CN5323 QGA2001C1-10 CONNECTOR,(1-10)DV MAIN
CN5324 QGA2001C1-05 CONNECTOR,(1-5)DV PRE/REC
CN5325 QGA2001F1-02 CONNECTOR,(1-2)FAN MOTOR
! CP5321 ICP-N25 CIRCUIT PROTECTOR
! CP5322 ICP-N25 CIRCUIT PROTECTOR
! CP5323 ICP-N25 CIRCUIT PROTECTOR
******************************
MAIN BOARD ASSEMBLY <03>
PW1 LPA10113-01D MAIN BOARD ASSY,SR-VS20E
LPA10113-02D MAIN BOARD ASSY,SR-VS20EK
IC1 JCP8020-MSD-2 IC
IC702 MM1113XF IC
IC703 MM1228XF IC
IC705 MM1117XF IC
IC706 PQ05TZ1U IC
IC707 AN3916 IC
IC712 MM1111XF IC
IC2601 BU4052BCF IC
IC2602 BA15218F-XE IC
IC2603 BU4052BCF IC
IC2605 BA15218F-XE IC
IC2606 BU4052BCF IC
IC2607 BU4052BCF IC
IC2608 BA15218F-XE IC
IC2609 LA7151 IC
IC2610 BU4053BCF IC
IC3001 HD6432194BA21F IC(MCU)
IC3002 S-80727AN-DQ-X IC
or S-80827ANUP-W IC
IC3003 AT24C16-10PC IC(EEPROM)
or 24LC16B/P IC(EEPROM)
IC3004 BA6956AN IC
IC3301 UPD780053GC042 IC(MCU)
IC3302 TC74HC4053AF IC
Q1 2SC4081/S/-X TRANSISTOR
Q2 2SC4081/S/-X TRANSISTOR
Q3 2SC4081/S/-X TRANSISTOR
Q4 2SC4081/S/-X TRANSISTOR
Q5 2SB1218A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
or 2SA1576A/QR/-X TRANSISTOR
Q7 2SD1819A/QRS/-X TRANSISTOR
or 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
Q8 2SD1819A/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
or 2SC4081/QRS/-X TRANSISTOR
Q9 2SB1218A/QR/-X TRANSISTOR
or 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q10 2SB1218A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
or 2SA1576A/QR/-X TRANSISTOR
Q17 DTC144WU TRANSISTOR
or PDTC144WU TRANSISTOR
or RN1309 TRANSISTOR
or UN521E TRANSISTOR
Q18 2SB1218A/QR/-X TRANSISTOR
or 2SA1576A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q21 2SB1218A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
or 2SA1576A/QR/-X TRANSISTOR
Q24 2SA1576A/QR/-X TRANSISTOR
or 2SB1218A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR
Q25 DTC144WU TRANSISTOR
or PDTC144WU TRANSISTOR
or RN1309 TRANSISTOR
or UN521E TRANSISTOR
Q38 2SD1819A/QRS/-X TRANSISTOR
or 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR
Q41 DTC144WU TRANSISTOR
or PDTC144WU TRANSISTOR
or RN1309 TRANSISTOR
or UN521E TRANSISTOR
