# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-32
C3717 NEA71CM-106X E CAPACITOR 10µF,16V
C3718 NEA71CM-106X E CAPACITOR 10µF,16V
C3725 NCB31HK-332X CAPACITOR 0.0033µF,50V
C3726 NCB31HK-682X CAPACITOR 0.0068µF,50V
C3728 NCB31CK-104X CAPACITOR 0.1µF,16V
C3729 NEA71CM-476X E CAPACITOR 47µF,16V
C3730 NEA71CM-476X E CAPACITOR 47µF,16V
C3731 NCB31CK-104X CAPACITOR 0.1µF,16V
C3733 NCB31HK-332X CAPACITOR 0.0033µF,50V
C3734 NCB31HK-682X CAPACITOR 0.0068µF,50V
L1011 NQL144K-100X COIL 10µH
L1012 NQL17CM-390X COIL 39µH
L1013 NQL17CM-390X COIL 39µH
L1015 NQL17CM-390X COIL 39µH
L1018 NQL17CM-390X COIL 39µH
L1501 NQL144K-100X COIL 10µH
L1502 NQL144K-100X COIL 10µH
L2001 NQL144K-100X COIL 10µH
L2002 NQL144K-100X COIL 10µH
L2003 NQL144K-100X COIL 10µH
L2004 NQL144K-100X COIL 10µH
L2005 NQL144K-100X COIL 10µH
L2006 NQL144K-100X COIL 10µH
L2007 NQL144K-100X COIL 10µH
L2008 NQL144K-100X COIL 10µH
L2009 NQL024J-2R2X COIL 2.2µH
L2010 NQL024J-100X COIL 10µH
L2011 NQL024J-120X COIL 12µH
L2015 NQR0276-001X COIL 10µH
L3103 NQL144K-100X COIL 10µH
L3104 NQL144K-100X COIL 10µH
L3111 NQL024J-150X COIL 15µH
L3131 NQL024J-150X COIL 15µH
L3151 NQL144K-100X COIL 10µH
L3531 NQL024J-120X COIL 12µH
L3532 NQL024J-270X COIL 27µH
L3533 NQL024J-120X COIL 12µH
L3534 NQL024J-270X COIL 27µH
L3701 NQL144K-100X COIL 10µH
L3702 NQL144K-100X COIL 10µH
L4001 NQL144K-100X COIL 10µH
LC1002 PELN1148-223X NOISE FILTER
LC1003 PELN1148-223X NOISE FILTER
LC1005 PELN1148-223X NOISE FILTER
LC3101 PELN0969-04Y NOISE FILTER
X1001 NAX0294-001X RESONATOR
X1002 NAX0005-001X CRYSTAL RESONATOR
X2001 NAX0141-001X CRYSTAL RESONATOR
X2003 NAX0206-001X CRYSTAL RESONATOR
X3101 NAX0218-001X CRYSTAL RESONATOR
K1001 NQR0129-002X FERRITE BEAD
K1011 NQR0129-002X FERRITE BEAD
K1012 NQR0129-002X FERRITE BEAD
K2001 NQR0129-002X FERRITE BEAD
(Sanwa)-V13SD1
K3101 NQR0129-002X FERRITE BEAD
J2001 QNZ0097-001 D CONNECTOR,DV IN/OUT
OT1 PU59915-105 #500SPACER0.01,C3102
OT2 PU59915-105 #500SPACER0.01,DV-GND
W1 NRSA02J-0R0X
MG RESISTOR,TL2023-TL2024 0Ø,1/16W
W2 NRSA02J-0R0X
MG RESISTOR,TL2022-TL2029 0Ø,1/16W
W3 NRSA02J-0R0X
MG RESISTOR,TL2074-TL2076 0Ø,1/16W
WR1 QUB350-04A1A WIRE,DV-GND
CN1001 QGA2001F2-10V CONNECTOR,(1-10)REG
CN1002 QGF1016F2-06W FFC/FPC CONNECTOR,(1-6)VHS MAIN
CN1101 QGB0801L1-26X CONNECTOR,(1-26)JIG
CN1501 QGF0508F1-20X FPC CONNECTOR,(1-20)PRE/REC
CN1502 QGF0503C1-15V FFC/FPC CONNECTOR,(1-15)MECHA
CN2001 QGF0508F1-26X FPC CONNECTOR,(1-26)DV PRE/REC
CN3501 QGA2001F2-06V CONNECTOR,(1-6)VIDEO
CN3701 QGF1016F4-08W FFC/FPC CONNECTOR,(1-8)AUDIO
******************************
LOADING MOTOR BOARD ASSEMBLY <55>
PW2 LPA10010-01A2 LOADING MOTOR BOARD ASSY
CN1 QGB2533K1-02 CONNECTOR
******************************
JOG BOARD ASSEMBLY <85>
PW6 LPA10126-01C6 JOG BOARD ASSY
UN7091 PEME0786-02 JOG SHUTTLE ASSY
FW7007 QUM036-06A4A4 PARA RIBON WIRE
