2-25
2.12 MECHANISM ASSEMBLY/DISASSEMBLY PROCEDURE TABLE
Step
Fig.
/Loc Part Name
No.
Point Note Discription
No.
1
A Cassette housing assembly/ B Mechanism assembly
T 2-13-1 2(S1),(L1) – (L5) 1
2
1
Drum assembly T 2-13-2 3(S2) 2,3
3
2 Motor bracket assembly T 2-13-2 4(S2) 2,4
4 3 Middle catcher assembly T 2-13-3 3(S2) —
5 4 Reel cover assembly T 2-13-3 (S2), 2(L6) 5
6 5 Pinch roller arm assembly T 2-13-4 (W1), (L7) 6
7 6 Sub brake assembly T 2-13-4 (P1), (W1), (L8) —
8 7 Band arm plate sub assembly T 2-13-4 (S3), (L9), (P2), (W2) 7,8
9 8 Tension arm sub assembly T 2-13-4 (P3) 8
10 9 EXIT guide arm assembly T 2-13-5 (W1) —
11 10 Swing arm assembly T 2-13-5 ——Position alignment
12 11 Sub deck assembly T 2-13-6 4(S2) 9 Position alignment
13 12 Main brake (Sup) assembly T 2-13-6 (P4), (L10) —
14 13 Main brake (Take up) assembly T 2-13-6 (P5), (L11) —
15 14 Reel disk assembly (Sup) T 2-13-7 ——
16 15 Reel disk assembly (Take up) T 2-13-7 ——
17 16 Prism T 2-13-7 (S2) —
18 17 Control plate T 2-13-7 2(L12) —
19 18 Guide rail (Take up) assembly T 2-13-8 4(S2) 10 Position alignment
20 19 Guide rail (Sup) assembly T 2-13-8 (S2), 2(L13) 10 Position alignment
21 20 Base plate assembly T 2-13-8 (S2), 2(L14) —
22 21 Ent. guide base assembly T 2-13-9 (S2) —
23 22 Worm wheel 2 T 2-13-9 — 11 Phase alignment
24 23 Timing belt T 2-13-9 ——
25 24 Center gear assembly T 2-13-9 ——
26 25 Reel drive pulley assembly T
2-13-10
(W1) —
27 26 Push plate T
2-13-10
(W1) —
28 27 Clutch lock gear(2) T
2-13-10
(W3) —
29 28 Clutch lock gear (1) T
2-13-10
(P6) —
30 29 Tension control arm assembly T
2-13-11
(L15) 12 Position alignment
31 30 Brake control arm assembly T
2-13-11
(W1), (L16) 12 Position alignment
32 31 Charge arm assembly T
2-13-11
(L17) 13 Position alignment
33 32 Connect gear 2 T
2-13-12
(S2) — (Phase alignment)
34 33 Connect gear 2 T
2-13-12
(S2) — (Phase alignment)
35 34 Rotary encoder assembly T
2-13-13
2(S2) 14 Phase alignment
36 35 Main cam T
2-13-13
(W1) 15 Phase alignment
37 36 Arm gear 1 assembly T
2-13-13
Collar 15,16 Position alignment
38 37 Centering arm assembly T
2-13-13
(L18) 15 Position alignment
39 38 Sub cam T
2-13-14
(S2) 17 Phase alignment
40 39 Arm gear 2 assembly T
2-13-14
— 17 Position alignment
41 40 Clutch lock lever assembly T
2-13-14
(L19) 17,18 Position alignment
42 41 Capstan motor T
2-13-15
(P7), Adjust nut — Vertical adjustment
43 42 Drum base deck T
2-13-15
3(S2) —
Table 2-12-1
To Next Page
