Basic Setup

The Basic Setup is where the initial programming must begin. Here, the

application fundamentals are established prior to conguration.

Note: In most cases the elevator control manufacturer will make the

adjustments in Basic Set-up but it is good to verify the correct settings.

Prior to conguring the elevator drive, view the controller reference parameter

list (provided by the elevator control manufacturer) to verify the parameters

required for the particular installation of the elevator drive.

The Basic Setup menu can be accessed by:

Home > Prog (F3) > Basic Setup.

All these parameters must be adjusted:

• US02 - System Units (Imperial/Metric)

• US03 - Motor Type (i.e. Induction geared or PM synch gearless)

• US04 - Control Type (i.e. Binary, Serial, Analog)

Next, the conguration must be loaded using US05. This step serves to load

the KEB drive with the correct limits and internal settings according to the

application:

• US05 - Load Conguration

(Write cong. to drive)

If loaded successfully, US05 should change from

Not congured to Conguration

OK,

indicating the drive and operator are synched.

If the US04 Control Type or US02 System Units settings are changed after

a conguration has been loaded, a new conguration must be written to the

drive. Writing the new conguration will NOT default all previous settings.

If the US03 Motor Type must be changed after a conguration has been

loaded, a new conguration must be written to the drive and writing the new

conguration WILL default all previous settings.

Then, enter the contract speed of the application, this will set the speed safety

limits internal to the drive:

• US06 - Contract Speed

SETUP OF THE BASIC INFO IS NOW COMPLETE!

Next, the inputs and outputs must be congured and assigned functionality

depending on the controller requirements.

4.3. Basic Setup

4.4. Inputs/Output

Conguration
