KEB COMBIVERT H6 Series User Manual

24
PRODUCT DESCRIPTION
2.4 Part code
x x H 6 x x x - x x x x
Reserved 0: Reserved
Reserved 0: Reserved
Softwareconguration
1-9: KEB default
A-Z: Customer version / special version
Hardwareconguration
Charging module
1: Version 1
2: Version 2
Active infeed controller (AIC)
1: Overload in accordance to technical data
2: Special overload behaviour
A-Z:
Customer- / special version
(rmwareanddownload)
Housing
Flat rear heat sink
B: 50mm E: 200mm
C: 100mm G: 300mm
Air heat sink
P: 50mm U: 200mm
S: 100mm W: 300mm
Control type A: KEB standard with control release
Power supply and
regenerative unit
D:
Active Infeed Converter (AIC) for sine-wave rege-
neration
F: Charging module
Series COMBIVERT H6 multi-axis drive system
Inverter size 14…26
Table 1: Part code
Thepartcodemaynotbeusedasordercode,butonlyforidentication!
