4 Installation and Connection
4.1 Construction of the device
Front view Remove the front cover Front without cover
• Pull with both hands low in the
cover.
•
Tilt cover forward to approx. 45
degrees, until the plates solve
above from the mounting.
•
Remove the cover forward.
Remove the cover from the
DC bus
•
Compress lug of the cover,
remove forward.
Figure 10: Front view of the device
DANGER
Hazardous voltage under the cover of the DC bus
► Secure isolation from supply of the DC bus at the power supply and
regenerative unit!
42
INSTALLATION AND CONNECTION
