View rear side of the device
Size G / W
X1A
U
V W
PE
Terminal connection Function
Conductor cross-sec-
tion
Tightening torque
X1A
U
Connectiontothelter.
Connect
inphase.
M10stud
for ring crimp connector
max.width30mm
12 Nm
110lbinch
V
W
PE
Connection for
shielding/
earthing
M8stud
for ring crimp connector
12 Nm
110lbinch
Figure 14: View of the bottom of the device size G / W
The terminal blocks meet the requirements of EN 60947-7-1.
46
INSTALLATION AND CONNECTION
