KEB COMBIVERT H6 Series User Manual

39
MECHANICAL INSTALLATION
3.4.6 AIC lter 3x400 V AC for switching frequency 8…16 kHz
Figure 1 Figure 2
214
150
199
9
455
470
2x
Ø 6,5
6
214
570
555 9
4x
Ø 6,5
100
200
249
Material number IN in A S in kVA PD in W Terminal
Tight-
ening
torque
PE-
terminal
Weight
in kg
Fig-
ure
14H6J4E-1000 16.5 11 160 10…25mm²
AWG20-4
3 Nm
M8
16 1
19H6J4E-1000
36 25 275
21.5 1
19H6J4F-1000 60 42 395
16…50mm²
AWG6-0
4 Nm
34 2
21H6J4F-1000 54 37.4 360 32 2
21H6J4F-1001 90 62 535 42.5 2
I
N: Rated current; S: Apparent power; PD: Power dissipation
Figure 8: AIC lter 3x400 V AC for switching frequency 8…16 kHz
Filter connection
RingcrimpconnectorsM8andtwoterminalblocks(4mm²)forfanandtemper-
aturesensor(KTY+/-)/switch(T1/2)areusedforsize26Z1.
IfastandardAICorEMClterisusedfortherectiermodule,KEBmustbe
consultedifmorethan6axesareconnected(eachwith20mcablelength).
