KEB COMBIVERT R6-N User Manual

Page 3.9 - 6 COMBIVERT R6-N © KEB, 2015-07
Dene CP-Parameters
2. Setting of a comparison level (LE.00) in set 2
3. Setting of a comparison level (LE.00) in set 3
1.) ud.15 = 1 ; CP.1
ud.16 = 0203h ; Parameter address for ru.03
ud.17 = 256 ; Display in the active set
2.) ud.15 = 2 ; CP.2
ud.16 = 0D00h ; Parameter address for LE.00
ud.17 = 4 ; Setting in set 2
3.) ud.15 = 3 ; CP.3
ud.16 = 0D00h ; Parameter address for LE.00
ud.17 = 8 ; setting in set 3
4.) ud.15 = 4 ; CP.4
ud.16=-1:off  ; CP.4 not displayed
ud.17 = xxx ; ud.17 no function
Set all other parameters like CP.4 to "off", that there is no display.
The acceptance of values occurs only after power-on reset of the operator.
3.9.4 Display standardization
KEBCOMBIVERTofferstheuserthepossibilitytodenetheownstandardizationsintheCPmode.Parame-
ters ud.18...20 serve asconversion,ud.21servesasspecication of the calculation method, decimal places,
as well as the displayed unity in KEB COMBIVIS.
