5. Error Diagnosis
The following chapter shall help you to avoid errors as well as help you to determine and remove the cause of
errors on your own.
5.1 Troubleshooting
5.1.1 General
If errormessagesormalfunctionsoccurrepeatedlyduringoperation,therstthingtodoistopinpointtheexact
error.Todothatgothroughthefollowingchecklist:
- Is the error reproducable?
For that reset the error and try to repeat it under the same conditions. If the error can be reproduced, the next
stepistondoutduringwhichoperatingphasetheerroroccurs.
- Does the error occur during a certain operating phase (e.g. always during regeneration)?
If so, consult the error messages and remove the causes listed there.
- Does the error occur or disappear after a certain time?
That may be an indication for thermal causes. Check, whether the COMBIVERT is used in accordance to the
ambient conditions and that no moisture condensation takes place.
5.1.2 Error messages and their causes
At KEB COMBIVERT error messages are always represented with an "E." and the appropriate error in the
display. Error messages cause the immediate deactivation of the modulation. Restart possible only after reset
or autoreset.
Malfunction are represented with an " A." and the appropriate message. Reactions to malfunctions can vary.
Status messages have no addition. The status message shows the current operating status of the inverter (e.g.
forward constant run, standstill etc.).
In the following the display and their cause are described.
Display COMBIVIS
Val-
ue
Meaning
Status Messages
nEtoF Power-off 64
Mains power failure; regenerative operation is further possi-
ble, if the disconnecting time E.nEt (Pn.14) > 0 s
nO_PU Power unit not ready 13
Powercircuitnotreadyornot identiedbythecontrol.The
error output O2 is set.
noP No operation 0 Control release (terminal ST) is not switched.
rEGEn Regeneration active 66 Regeneration active (regenerative operation)
Stb Standby 69
R6 regenerative unit in stand-by operation (motoric opera-
tion)
bbL Base-Block 76 Count down of the base-block time, R6-N released
rinit Re-init device 42 Re-initialisation
Error Messages
continued on the next page
