KEB COMBIVERT R6-N User Manual

Hardware
© KEB, 2015-07 COMBIVERT R6-N Page1.3 - 3
1
10
1.3 Hardware
1.3.1 Control boards
1.3.1.1 Control board 1N.R6
Connection terminals of the control board
X2A.10...23
X2A.24...29
X4B
5 4 3 2 1
9 8 7 6
5 4 3 2 1
9 8 7 6
X2D
X2A Control terminal strip Install control and mains cable separately !
X2D Master/slave synchronization socket
X4B Operator interface No direct PC connection
1.3.1.2 Control terminal strip X2A
