KEB COMBIVERT R6-N User Manual

Parameter summary
© KEB, 2015-07 COMBIVERT R6-N Page3.1 - 3
3
10
3. Functions
3.1 Parameter summary
3.1.1 Parameter list R6-N
Legend
Parameter: Parameter group, number and name (sorted acc. to parameter group and number)
Addr.: Parameter address in hex
R: Password level rw => write and read, ro => only readable
P: p => set-programmable; np => not set-programmable
E: E => Enter parameter
Lower limit: Minimum value (standardized); the non-standardized value results by division by the resolution
Upper limit: Maximum value (standardized); the non-standardized value results by division by the resolution
Step: Step size, resolution
Default: Default value (standardized); the non-standardized value results by division by the resolution
  LTK=>thedefaultvalueisdependentonthepowercircuitidentication
Unit: Unit
Reference: furtherinformationtothisparameteronspeciedpage(notchapter)
Parameter Addr. R P E Lower limit Upper limit Default Step Unit See on page
An.31 ANOUT1 function 0A1Fh rw p E 0 26 2 1 --- 3.3-3, 3.3-4
An.32 ANOUT1 value 0A20h rw p --- -100,0 100,0 0,0 0,1 % 3.3-3, 3.3-4, 3.3-6
An.33 ANOUT1 gain 0A21h rw p --- -20,00 20,00 1,00 0,01 --- 3.3-3, 3.3-5, 3.3-6
An.34 ANOUT1 offset X 0A22h rw p --- -100,0 100,0 0,0 0,1 % 3.3-5, 3.3-6
An.35 ANOUT1 offset Y 0A23h rw p --- -100,0 100,0 0,0 0,1 % 3.3-5
An.41 ANOUT3 function 0A29h rw np E 0 26 12 1 --- 3.3-3, 3.3-4, 3.7-3
An.42 ANOUT3 value 0A2Ah rw np --- -100,0 100,0 0,0 0,1 % 3.3-6
An.43 ANOUT3 gain 0A2Bh rw np --- -20,00 20,00 1,00 0,01 --- 3.3-5
An.46 ANOUT3 period 0A2Eh rw np E 1 240 1 1 s 3.3-3, 3.3-4, 3.4-13
An.47 ANOUT4 function 0A2Fh rw np E 0 26 12 1 --- 3.3-4
An.48 ANOUT4 value 0A30h rw np --- -100,0 100,0 0,0 0,1 % 3.3-6
An.49 ANOUT4 gain 0A31h rw np --- -20,00 20,00 1,00 0,01 --- 3.3-5
An.52 ANOUT4 period 0A34h rw np E 1 240 1 1 s 3.3-4, 3.4-13
cS.02 Regeneration level 0F02h rw np --- 100 120 103 1 % 3.2-6, 3.5-4, 4.2-4
cS.03 Mains frequency max. tolerance 0F03h rw np --- 0 5 5 1 % 3.6-7, 4.2-4, 5.1-3
cs.04 Switch off delay OSF 0F04h rw np --- -10 +10 0 1 ° 3.5-5
cS.06 puls off level 0F06h rw np --- -10000 0 -8 1 kW 3.5-4, 4.2-4, 4.2-5
cS.07 Mainslterquality 0F07h rw np E 1 8 1 1 --- 3.5-5
cS.08 Kp commutation reactor 0F08h rw np E 7 13 10 1 --- 3.5-5
cS.09 Ki commutation reactor 0F09h rw np E 5 11 8 1 --- 3.5-5
cS.11 Kpharmoniclter 0F0Bh rw np E 7 13 10 1 --- 3.5-5
cS.12 Kiharmoniclter 0F0Ch rw np E 5 11 8 1 --- 3.5-5
cS.15 DT1 threshold 0F0Fh rw np E 0 255 255 1 --- 3.5-5
cS.17 Actual deviation E.net 0F11h rw np E 10 100 50 1 --- 3.5-5
di.00 PNP / NPN selection 0B00h rw np E 0 1 0 1 --- 3.4-2, 3.4-4, 7.1-3
di.01 Select signal source 0B01h rw np E 0 4095 0 1 ---
3.2-17, 3.2-18, 3.4-2, 3.4-
3, 3.4-4, 3.4-5
di.02 digital input setting 0B02h rw np E 0 4095 0 1 ---
3.2-17, 3.2-18, 3.4-2, 3.4-
4, 3.4-5
di. 03 digitalnoiselter 0B03h rw np E 0 127 0 1 ms 3.4-2, 3.4-6
di.04 Invert. Digital inputs 0B04h rw np E 0 4095 0 1 --- 3.4-2, 3.4-6
di.05 Edgetriggeredip-op 0B05h rw np E 0 4095 0 1 --- 3.4-2, 3.4-6
di.06 select strobe source 0B06h rw np E 0 4095 0 1 --- 3.4-2, 3.4-6, 3.4-7
di.07 Strobe mode 0B07h rw np E 0 2 0 1 --- 3.4-2, 3.4-6, 3.4-7, 3.4-8
di.08 input strobe dependence 0B08h
rw np E 0 4095 0 1 --- 3.4-2, 3.4-6, 3.4-7
di. 09 reset input selection 0B09h rw np E 0 4095 3 1 --- 3.4-2, 3.4-8, 3.4-9
di.10 reset input slope sel. 0B0Ah rw np E 0 4095 3 1 --- 3.4-2, 3.4-8
di.11 I1 functions 0B0Bh rw np E -2^31 2^31-1 1 1 hex 3.4-3,3.4-8,3.4-9,3.4-10
di.22 ST functions 0B16h rw np E -2^31 2^31-1 128 1 hex 3.4-8, 3.4-9, 3.4-10
di.24 I1 + function 0B18h rw np E 0 6 0 1 --- 3.4-8, 3.4-9
di.35 ST + function 0B23h rw np E 0 6 0 1 --- 3.4-8, 3.4-9
di.36 Software ST input sel. 0B24h rw np E 0 4095 0 1 --- 3.4-9, 3.4-10
di.37 Locking ST input selection 0B25h rw np E 0 4095 0 1 --- 3.4-9, 3.4-10
di.38 set deactivation delay ST 0B26h rw np --- 0,0 10,0 0,0 0,1 s 3.4-9, 3.4-10
do.00 Condition 0 0C00h rw p E 0 92 20 1 ---
3.2-8, 3.4-2, 3.4-12, 3.4-
13, 3.4-14
do.01 Condition 1 0C01h rw p E 0 92 3 1 --- 3.4-15
continued on the next page
