KEB COMBIVERT R6-N User Manual

Page1.3 - 6 COMBIVERT R6-N © KEB, 2015-07
Hardware
1.3.1.4 Synchronisation line X2D
X2D Master/Slave Synchronization in parallel
connection of two regenerative units.
No. Function
1 8
1 IGBT off, high
2 IGBT off, low
3 SLAVE active, high
4 IGBT on, high
5 IGBT on, low
6 SLAVE active, low
7 –
8 –
If two regenerative units are switched parallely they have to be connected via patch cable (Part No. 00F50C3-
1010 1m).
