KEB COMBIVERT R6-N User Manual

Digital in- and outputs
© KEB, 2015-07 COMBIVERT R6-N Page3.4 - 9
3
10
di.36 software ST input sel.
di.37 ST lock input sel.
di.38 turn off ST delay time
Fr.07 select inputs f. paraset
Fr.11 select inputs f. rst set
LE.17 timer 1 start input sel.
LE.19 timer 1 reset input sel.
LE.22 timer 2 start input sel.
LE.24 timer 2 reset input sel.
Pn.04 ext. fault input selection
The following table gives an overview of all functions, which can be assigned to a digital input with parameters
di.11...di.22 (several functions are possible).
di.11...di.22: Input function
Bit Value Description Fct. Para
1)
0
1:Modusmaster/slave(only
di.11..di.13)
Specify input for master/slave via external input
(see pn.19)
Pn.31
7 128:reseterror Release reset di. 09
11 2048:Set
Parameter set selection
Fr.07
12 4096:resetset Fr.11
13 8192:externalfault Triggers error state at the inverter Pn.04
17 131072:runtimer1
start / stop timer
LE.17
18 262144:resettimer1 LE.19
19 524288:runtimer2 LE.22
20 1048576:resettimer2 LE.24
31 2147483648:I+function one additional function („+“ function) is selected ---
Not listed bits are not assigned.
1)
displays the function-related parameter, which corresponds to the value in di.11… di.22.
The next table indicates an overview of the additional functions, which can be assigned to a digital input with
parameters di.24...di.35 (only one additional function per input is possible / bit 31 „I+ function must be activated
fortheappropriateinput):
di.24...di.35: input „+“ function
Value Description Fct. Para
1)
5:softwareST(di.35no
funct.)
any digital input gets the function "control release" (soft-
ware-emulation / function can not be placed on the input ST)
di.36
6:STlock(di.35nofunct.) Setting the input leads to locking of the software control release di.37
Not listed values are not assigned.
1)
the column „Fct. para“ displays the function-related parameter, which corresponds to the value in di.11...di.22
3.4.11 Software ST and locking of the control release
di.36 software ST, di.37 ST lock, di.38 turn off ST delay time
