3.2 Operating and appliance data
The parameter groups „ru“, „In“ and „SY“ are described in this chapter. They serve for operational monitoring,
erroranalysisandevaluationaswellasforunitidentication.
3.2.1 Overview of the ru-Parameters
The ru parameter group displays the multimeter of the inverter. Here voltages, currents etc. are displayed, with
those a statement about the actual operating condition of the inverter can be made. Especially during the start-
uporerrorsearchattheunitthiscanbeagreathelp.Followingparametersareavailable:
ru. 00 Inverter state
ru. 01 Actual operation mode
ru. 03 Actual line frequency
ru. 08 AC-Phase current L1
ru. 09 AC-Phase current L2
ru. 10 AC-Phase current L3
ru. 11 Input voltage
ru. 13 Act. DC utilization
ru. 14 Peak DC utilization
ru. 15 DC current
ru. 16 DC output current / peak value
ru. 17 AC current
ru. 18 DC voltage / reference value
ru. 19 DC output voltage
ru. 20 DC output voltage / peak value
ru. 21 Input terminal state
ru. 22 Internal input state
ru. 23 Output condition state
ru. 24 Stateofoutputags   
ru. 25 Output terminal state
ru. 26 Active parameter set
ru. 33 Analogoutput1displaybeforeamplication
ru. 34 Analogoutput1displayafteramplication
ru. 38 Power module temperature
ru. 39 OL counter display
ru. 40 Power on counter
ru. 41 Modulation on counter
ru. 43 Timer 1 display
ru. 44 Timer 2 display
ru. 68 Rated DC voltage
ru. 80 Digital output state
ru. 81 Actual power
ru. 82 Total regen
ru. 83 Total motor
ru. 84 Total net
ru. 85 Actual net
