Calibration Reference B-13
AC calibration commands
The :AC commands perform comprehensive (user) calibration of the ACV and ACI func-
tions. Table B-3 summarizes these calibration commands.
Table B-3
AC calibration commands
Command Description
:CALibration
:PROTected
:AC
:STEP1 10mV AC at 1kHz calibration step.
:STEP2 100mV AC at 1kHz calibration step.
:STEP3 100mV AC at 50kHz calibration step.
:STEP4 1V AC at 1kHz calibration step.
:STEP5 1V AC at 50kHz calibration step.
:STEP6 10V AC at 1kHz calibration step.
:STEP7 10V AC at 50kHz calibration step.
:STEP8 100V AC at 1kHz calibration step.
:STEP9 100V AC at 50kHz calibration step.
:STEP10 700V AC at 1kHz calibration step.
:STEP11 100mA AC at 1kHz calibration step.
:STEP12 1A AC at 1kHz calibration step.
:STEP13 2A AC at 1kHz calibration step.
