1-10 Performance Verification

2. Select the AC volts function by pressing the

ACV

key.

3. Set the Model 2700 for the 100mV range; make sure that REL is disabled.

4. Source 1kHz and 50kHz AC voltages for each of the ranges summarized in Table 1-3,

and make sure that the respective Model 2700 readings fall within stated limits.

Table 1-3

ACV reading limits

ACV

range

Applied AC

voltage

1kHz reading limits

(1 year, 18°C to 28°C)

50kHz reading limits

(1 year, 18°C to 28°C)

100mV

10V

100V

750V

100.0000mV

1.000000V

10.00000V

100.0000V

700.000V*

99.910 to 100.090mV

0.99910 to 1.00090V

9.9910 to 10.0090V

99.910 to 100.090V

699.36 to 700.64V

99.830 to 100.170mV

0.99830 to 1.00170V

9.98300 to 10.0170V

99.830 to 100.170V

698.79 to 701.21V

* If the 5725A ampliﬁer is not available, change the 700V @ 50kHz step to 220V @ 50kHz. Reading

limits for 220V @ 50kHz = 219.36 to 220.64V.
