Wave Functions (6221 Only)
Section 7 topics
Wave function overview, page 7-2 Front panel wave function operation, page 7-8
Setting waveform parameters, page 7-3 Using the wave function menu, page 7-8
Editing parameters, page 7-3 Generating a sine wave, page 7-10
Amplitude and offset editing, page 7-3 Generating an arbitrary waveform, page 7-11
Amplitude and units, page 7-3
Ranging, page 7-3 Remote wave function operation, page 7-12
Range options, page 7-3 Programming sine waves, page 7-13
Arbitrary waveform ranging, page 7-4 Programming arbitrary waveforms, page 7-14
Frequency, page 7-4 SCPI commands — wave functions, page 7-15
Offset, page 7-4
Duty cycle, page 7-5
Phase marker, page 7-6
Duration, page 7-7
Externally triggered waveforms, page 7-7
NOTE The information in this section is an abbreviated version
of the information in Section 7 of the Reference Manual.
Refer to Section 7 of the Reference Manual for complete
details and additional information that is not provided in
this manual.
