Model 6220/6221 User’s Manual SCPI Tables (Abridged) B-3
Return to Appendix B tables
Table B-3
Format command summary
Command Description Default
FORM Reading format commands:
[:DATA] <type> Specify data format: ASC, SRE, or DRE ASC
:ELEM <item list> Specify data elements: READ, TST, UNIT, RNUM, SOUR,
COMP, AVOL (or ALL or DEF)
READ,
TST
:BORD <name> Specify byte order: NORM or SWAP. (Note)
:SREG <name> Select format for reading status registers: ASC, HEX, OCT or BIN. ASC
Note: *RST default is NORM. SYST:PRES default is SWAP.
Table B-4
Output command summary
Command Description Default
OUTPut Source output control:
[:STAT]? Turn output on or off (standby). OFF
:LTE <b> Connect output low to earth ground (ON) or float output low (OFF). OFF
:ISH <name> Connect triax inner shield to OLOW (output low) or cable GUAR. OLOW
:RESP <name> Set the output response for 6221: FAST or SLOW. FAST
:INT Interlock:
:TRIP? Returns a “0” if interlock is tripped (open) or a “1” if interlock is closed
(output enabled).
Table B-5
Sense command summary
Command Description Default
SENS Commands for readings from 2182/2182A:
:DATA? Return the latest pre-math delta reading.
:FRES? Same as :DATA? except the reading can only be returned once.
:AVER Averaging filter:
:TCON <name> Select filter control: MOV or REP MOV
:WIND <NRf> Set filter window as % of range: 0 to 10 0.00
:COUN <NRf> Specify filter count (size): 2 to 300 10
[:STAT] <b> Enable or disable averaging filter. OFF
