Model 6220/6221 User’s Manual Getting Started 1-13
Return to Section 1 topics
Menus
Many aspects of operation are configured through menus. A direct access menu
can be opened by pressing a single key, and other menus require that the
CONGIF key be pressed before pressing another key.
CONFIG menus
Models 6220 and 6221:
CONFIG > SWP opens CONFIGURE SWEEPS menu (Section 4).
CONFIG > COND opens DIFF CONDUCTANCE menu (Section 5).
CONFIG > DELTA opens CONFIGURE DELTA menu (Section 5).
CONFIG > TRIG opens CONFIGURE TRIGGER menu (Section 8 of the
622x Reference Manual).
CONFIG > RECALL opens CLEAR BUFFER? menu (Section 6).
CONFIG > MATH opens CONFIGURE MATH menu (Section 6).
Model 6221 only:
CONFIG > PULSE opens CONFIG PULSE DELTA menu (Section 5).
CONFIG > WAVE opens CONFIGURE WAVEFORM menu (Section 7).
CONFIG > OUTPUT opens OUTPUT RESPONSE menu (Section 3).
Direct access menus
Models 6220 and 6221:
COMM opens COMMUNICATIONS SETUP menu (page 1-17).
ADDR opens ADDRESS = (value) menu for GPIB.
UNITS opens READING UNITS menu (Section 3).
RECALL opens menu for stored readings and statistics (Section 6).
SAVE opens SAVED SETUP MENU (page 1-18).
SETUP opens RESTORE SETUP menu (page 1-18).
TRIAX opens CONFIGURE TRIAX menu (Section 2).
MENU opens MAIN MENU (see “MAIN menu” below).
NOTE “Press CONFIG > Press SWP” is an example of a key-
press sequence. To open the menu, press the CONFIG
key and then the SWP key.
NOTE All of the following keys to open direct access menus (ex-
cept RECALL) can also be opened by first pressing the
CONFIG key.
