7-16 Wave Functions (6221 Only) Model 6220/6221 User’s Manual
Return to Section 7 topics
SOURce[1]:WAVE:ARM Arms 6221 for waveform output.
SOURce[1]:WAVE:INITiate Starts waveform output.
SOURce[1]:WAVE:ABORt Aborts waveform output.
SOURce[1]:WAVE:DURation:TIME <NRf> Sets waveform time duration.
<NRf> = 100e-9 to 999999.999 (s)
or INFinity.
INFinity
SOURce[1]:WAVE:DURation:CYCLes <NRf> Sets waveform duration in cycles.
<NRf> = 0.001 to 99999999900
or INFinity.
INFinity
SOURce[1]:WAVE:EXTRig[:ENABle] <b> Enables/disables mode to externally
trigger the waveform generator. *
<b> = ON or OFF
OFF
SOURce[1]:WAVE:EXTRig:ILINe <NRf> Specify trigger link input trigger line.
<NRf> = 0 (none) or 1 to 6
0
SOURce[1]:WAVE:EXTRig:IGNore <b> Sets whether or not to restart
waveform upon retriggering.
<b> = ON or OFF
OFF
SOURce[1]:WAVE:EXTRig:IVALue <NRf> Sets inactive value to output before/
after waveform.
<NRf> = -1 to +1
0.00
* Waveform triggering available with firmware revision level A03 and later. See Section 7 of the Model 6220/6221
Reference Manual for details.
Table 7-4 (cont.)
Waveform function commands
Command Description Default
