TP-6714 4/10100 Section 6 Communications
6.4.1 File Transfer
The USB Access screen opens automatically when a
device is connected to the controller’s USB port. See
Figure 6-10. Select Upload or Download as described
in the following procedure.
Procedure to Transfer Files
1. Insert the USB mass storage device into the USB
port on the controller’s main logic board. See
Figure 6-1 for the port location.
2. Press the Download button to load new files from a
memory device to the controller. Or, press the
Upload button to load files from the controller
through the USB port to a memory device.
3. Use the down button to scroll through the list of
available files.
4. When the desired file is displayed, press the Sel
button to select the file and start transferring the
file. See Figure 6-9 for file names.
Note: Do not disconnect the device from the USB
port during file transfer.
A message on the display indicates when file
transfer is complete.
USB Connected
Download Upload
Download to Control
Filename
Free Space #### Kb
B Sel Back
Upload to USB
File/Data Log
Back Next
Upload to USB
Filename
Free space #### Kb
B Sel Back
USB Data Logger
Start Stop Back
(appears only when USB device is connected)
Figure 6-10 USB Access Screens
To Next Page
