Appendix B Screen Summaries
For reference, this section lists the items displayed during normal operation, and the information and settings shown in
the View and Setup screens.
Operation Screens
Main Screen
D System Status
D Next Exercise Time and Date
D Normal and Emergency Voltage
D Frequency
D Normal Source Voltage
D Lamp Test
D Emergency Source Voltage
D Current, Amps
D Time/Date
D Daylight Saving Time Info
D Preferred Source
D Source-Source Type
D Commit/No Commit to Transfer
D Standard/Programmed Transition
D Phase Rotation (3-phase only)
D In-Phase Monitoring Enabled/Disabled
Test Sequence Screens
D Enter Password
D Type of Test
d Loaded/Unloaded/Auto Load/Sync Check
d Auto Load Test Run Time
D Test Sequence Status Screens
d Active Time Delay with Time Remaining
d Source Voltages
d End Delay Button
d End Test Button
d Phase Angle (sync check only)
Exerciser Sequence (during exercise run)
D Exerciser Active
D Source Voltages
D Time Remaining (in exercise run)
D EndExerciseButton
View Screens
Main Screen
D System Status
D Next Exercise Time and Date
D Normal and Emergency Voltage
View Event History
D Event Description
D Date and Time of event
View Maintenance Records
D Total Min Not Preferred
D Reset Min Not Preferred
D Total Min in Standby
D Reset Min in Standby
D Total Min Operation
D Reset Min Operation
D Total Transfers
D Reset Transfers
D Total Fail Transfer
D Reset Fail Transfer
D Total Loss Pref Tran
D Reset Lodd Pref Tran
D Transfer Time N>E
D Transfer Time E>N
D System Start Date
D Last Maint Date
D Last Loss Duration
D Last Loss Date/Time
D Minimum Values
D Maximum Values
D Dual Source Connect Time
D S1 to Open Time
D S1 to Close time
D S2 to Open Time
D S2 to Close Time
