STRUCTURE AND FUNCTION
EX20 Series 60-23
TILT CYLINDER
Item Unit FD100–160E
Outside diameter of cylinder mm 142
Inside diameter of cylinder mm 125
Diameter of piston rod mm 60
Stroke mm 24
Seal type – U–packing, piston ring
Weight kg–each
TILT CYLINDER
