ELECTRICAL SYSTEM REMOVAL AND INSTALLATION
30-14 EX20 Series
ELECTRICAL SYSTEM
Stop lamp
switch
Brake oil
switch
Parking brake
switch
Coolant level
switch
Water temp.
sensor
Air cleaner
sensor
T/M valve
Speed meter
sensor
T/C oil sensor
Fuel level
sensor
