WEIGHT TABLE REMOVAL AND INSTALLATION
30-4 EX20 Series
WEIGHT TABLE
Unit: kg
FD100 FD115 FD135 FD150E FD160E Remaks
Engine assembly 538
Torque converter assembly 265
Transmission assembly 360 Dry
Axle
Front 785 820 Excluding frontwheel
Rear 425 560
Excluding power
steering cylinder
Wheel (each)
Front 80 95 105 110 115
Rear 70 85 95 95 105
Over head guard 131
Counterweight 4,330 5,390 5,790 6,670 7,100
Lift cylinder 85 90 105 110 Lift high 1 m (each)
Tilt cylinder 50 Lift high 1 m (each)
45 55
Must 1,524 1,717 1,782 1,817
Lift high 3 m Excluding
fork, fork carriage
Fork carriage assembly 630 700 820 940 Excluding fork
Fork (each) 157 195 220 240 260 Length: 1,220 mm
