METHOD FOR CLEANING FUEL PREFILTER ELEMENT
WARNING
Do not bring any open flame close.
Items to be prepared
Container to catch the fuel
1.
Set the machine in the posture shown in the figure.
1)
Start the engine.
2)
Set the lock lever to FREE position (F).
Be
sure to operate the lock lever by the operating por-
tion on the top.
3)
Operate the work equipment control lever slowly to the
right and left to swing the upper structure so that the
fuel prefilter comes between the tracks.
4)
Operate the work equipment control levers, and lower
the work equipment to the ground.
5)
Set the lock lever to LOCK position (L).
Be
sure to operate the lock lever by the operating por-
tion on the top.
6)
Stop the engine.
2.
Pull the engine rear cover (1) backward to open it.
Open
the engine rear cover (1) fully and it is secured by
rod (2).
MAINTENANCE PROCEDURE MAINTENANCE
4-34
