WHEELS, TIRES 14
105
– Hold the rear wheel and remove the wheel spindle. Take the
rear wheel out of the link fork.
Info
Do not operate the foot brake lever when the rear wheel
is removed.
H03002-10
–
Remove spacers
4
.
14.4 Installing the rear wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
H03001-10
Main work
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change the rear wheel bearing.
–
Clean and grease shaft seal rings
1
and contact surfaces
A
of the spacers.
Long-life grease ( p. 161)
– Insert the spacers.
– Clean and grease the wheel spindle.
Long-life grease ( p. 161)
V00367-10
–
Position rear wheel and insert wheel spindle
2
.
– Mount the chain.
The brake linings are correctly positioned.
