SERVICE WORK ON THE ENGINE 19
135
I00454-10
–
Check whether air bubbles are visible in the hose
5
.
» If air bubbles are visible:
– Repeat the entire procedure until air bubbles are no
longer visible.
– Mount the diagnostics connector on the holder.
Finishing work
– Mount the seat. ( p. 71)
19.4 Cleaning the oil screen in the oil tank
Note
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance with
the applicable regulations.
Preparatory work
– Raise the motorcycle with a lift stand. ( p. 59)
– Remove main silencer. ( p. 75)
– Remove the seat. ( p. 70)
– Remove the fuel tank. ( p. 76)
– Remove the air filter box cover. ( p. 72)
I00456-10
Main work
–
Remove screws
1
.
–
Loosen screws
2
.
I00457-10
–
Remove fuel vapor valve
3
from the bracket and hang it to
the side.
