6 CONTROLS
16
6.1 Clutch lever
W00295-10
Clutch lever
1
is fitted on the handlebar on the left.
The clutch is activated hydraulically and adjusts itself automati-
cally.
6.2 Hand brake lever
W00292-10
Hand brake lever
1
is fitted on the right side of the handlebar.
The front brake is engaged using the hand brake lever.
6.3 Throttle grip
W00291-10
Throttle grip
1
is fitted on the right side of the handlebar.
6.4 Horn button (All EXC models)
W00290-11
Horn button
1
is fitted on the left side of the handlebar.
Possible states
• The horn button is in the basic position
• The horn button is pressed – The horn is operated in this
position.
