23 TECHNICAL DATA 122
Homologated weight without fuel, approx. (All EXC‑F models) 108.5 kg (239.2 lb.)
Weight without fuel, approx. (All XCF-W models) 107.2 kg (236.3 lb.)
Maximum permissible front axle load 145 kg (320 lb.)
Maximum permissible rear axle load 190 kg (419 lb.)
Maximum permissible overall weight 335 kg (739 lb.)
23.5 Electrical system
Battery YTX4L-BS Battery voltage: 12 V
Nominal capacity: 3 Ah
Maintenance-free
Speedometer battery CR 2430 Battery voltage: 3 V
Fuse 58011109105 5 A
Fuse 75011088010 10 A
Fuse 58011109120 20 A
Headlight HS1 / socket PX43t 12 V
35/35 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Indicator lamps W2.3W / socket W2x4.6d 12 V
2.3 W
Turn signal (All EXC‑F models) R10W / socket BA15s 12 V
10 W
Brake/tail light LED
License plate lamp (All EXC‑F models) W5W / socket W2.1x9.5d 12 V
5 W
23.6 Tires
Validity Front tires Rear tires
(All EXC‑F models) 80/100 - 21 M/C 51M TT
MAXXIS MAXX CROSS SI
140/80 - 18 M/C 70R TT
MAXXIS MAXX ENDURO
(All XCF-W models) 80/100 - 21 51M TT
Dunlop GEOMAX MX51FA
110/100 - 18 64M TT
Dunlop GEOMAX MX51
Additional information is available in the Service section under:
http://www.ktm.com
23.7 Fork
23.7.1 EXC‑F EU, EXC‑F AUS, XCF‑W
Fork part number 14.18.7L.67
Fork WP Suspension Up Side Down 4860 MXMA PA
Compression damping
Comfort 22 clicks
Standard 20 clicks
Sport 18 clicks
Rebound damping
Comfort 20 clicks
Standard 18 clicks
Sport 16 clicks
Spring preload - Preload Adjuster
Comfort 1 turn
Standard 2 turns
Sport 2 turns
Spring length with preload spacer(s)
Weight of rider: 65… 75 kg (143… 165 lb.) 513 mm (20.2 in)
