21 TECHNICAL DATA
114
Sport 10 clicks
Full payload 10 clicks
Fitted length 391 mm (15.39 in)
Spring rate
Standard 75 N/mm (428 lb/in)
Shock absorber fluid ( p. 119) SAE 2.5
21.9 Chassis tightening torques
Screw, chain guard EJOT 1.5 Nm (1.11 lbf ft)
Screw, combination instrument EJOT 1 Nm (0.7 lbf ft)
Screw, combination switch EJOT PT
®
K50x18 T20 2 Nm (1.5 lbf ft)
Screw, radiator guard EJOT PT K50x14 T20 2 Nm (1.5 lbf ft)
Screw, side cover on spoiler EJOT 2 Nm (1.5 lbf ft)
Screw, side stand sensor EJOT 1 Nm (0.7 lbf ft)
Fitting, side stand sensor M4 2 Nm (1.5 lbf ft)
Spoke nipple, front wheel M4.5 4 Nm (3 lbf ft)
Spoke nipple, rear wheel M4.5 4 Nm (3 lbf ft)
Brake line guide on the frame M5 2 Nm (1.5 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, brake line holder on link
fork
M5 5 Nm (3.7 lbf ft)
Screw, cable on starter motor M5 3 Nm (2.2 lbf ft)
Screw, combination switch, left M5 3.5 Nm (2.58 lbf ft)
Screw, electrical holder in fuel
tank
M5 2 Nm (1.5 lbf ft)
Screw, electrical holder under 12-
V battery
M5 10 Nm (7.4 lbf ft)
Screw, exhaust heat shield M5 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, foot brake lever stub M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, fuel hose clamp on fuel
tank
M5 5 Nm (3.7 lbf ft)
Screw, fuel level sensor M5 3 Nm (2.2 lbf ft)
Screw, fuel pump M5 4 Nm (3 lbf ft)
Screw, fuel tank closure flange M5 2.5 Nm (1.84 lbf ft)
Screw, headlight mask M5 2 Nm (1.5 lbf ft)
Screw, pressure regulator M5 4 Nm (3 lbf ft)
Screw, radiator fan cover M5 3.2 Nm (2.36 lbf ft)
Screw, radiator guard M5 3.5 Nm (2.58 lbf ft)
Screw, throttle grip M5 3.5 Nm (2.58 lbf ft)
Screw, trim M5x12 3.5 Nm (2.58 lbf ft)
Screw, trim M5x20 2 Nm (1.5 lbf ft)
Nut, valve M6 4.5 Nm (3.32 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
