Finishing work
– Install the headlight mask with the headlight. ( p. 84)
– Check the headlight setting. ( p. 86)
11.19 Removing the air filter
Preparatory work
– Open the fuel tank filler cap. ( p. 19)
– Remove the seat. ( p. 49)
S03338-10
Main work
–
Remove screws
1
.
–
Remove the upper part of the air filter box
2
.
S03339-10
Note
Engine damage Unfiltered intake air has a negative effect on
the service life of the engine.
Dust and dirt will enter the engine without an air filter.
– Only operate the vehicle if it is equipped with an air filter.
–
Remove air filter
3
.
11.20 Installing the air filter
S03340-10
Main work
– Clean the air filter box.
–
Mount air filter
1
.
Info
The air filter must lie flush against the air filter box
along the entire sealing surface
A
.
If the air filter is not mounted correctly, dust and dirt
may enter the engine and result in damage.
–
Hook air filter box top
2
into the front of the air filter box
and swing down.
S03338-11
–
Mount and tighten screws
3
.
Guideline
Screw, upper part of
the air filter box
M6 2 Nm (1.5 lbf ft)
