6 CONTROLS
18
6.13 Grab handles
S03277-10
The grab handles
1
are used for moving the motorcycle around.
If you carry a passenger, the passenger can hold onto the grab
handles during the trip.
6.14 Passenger foot pegs
S03337-01
The passenger foot pegs can be folded up and down.
Possible states
• Passenger foot pegs folded up – For operation without a pas-
senger.
• Passenger foot pegs folded down – For operation with a pas-
senger.
6.15 Shift lever
401950-10
The shift lever
1
is mounted on the left side of the engine.
401950-11
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
