6 CONTROLS
14
6.1 Clutch lever
S03266-10
Clutch lever
1
is fitted on the handlebar on the left.
The clutch is activated hydraulically and adjusts itself automati-
cally.
6.2 Hand brake lever
S03267-10
The hand break lever
1
is fitted on the right side of the handle-
bar.
The hand brake lever operates the front brake.
6.3 Throttle grip
S03268-10
The throttle grip
1
is fitted on the right side of the handlebar.
6.4 Horn button
S03269-10
Horn button
1
is fitted on the left side of the handlebar.
Possible states
• The horn button is in the basic position
• The horn button is pressed – The horn is operated in this
position.
