(1) Hydraulic unlock switch
4. Horn switch
When pressing the horn switch, the horn will beep.
The
horn switch is operative even when the starter key
is in the [STOP] position.
(1) Horn switch
5. Travel speed switch
Travel speed will increase when you press down the
travel-speed-switch.
Switching the dual travel speed:
1. When
pressing the travel-speed-switch, the buzzer
beeps twice, the travel speed changes from low to
high speed, and the
symbol lights up.
2. When
pressing the travel-speed-switch again, the
buzzer beeps once, the travel speed changes from
high to low speed, and the
symbol goes out.
(1) Travel speed switch (2) Speed indicator light
NOTE :
• When
activating the travel-speed-switch, press
it completely. The travel-speed-switch is
operative only when the travel system is
unlocked.
• Each time the travel-speed-switch is pressed,
the travel speed is switched between high and
low speed.
6. Working light switch
The working-light-switch is operative with the starter
key in the [RUN]
position.
The working-light-switch has three positions.
1. When the working-light-switch is positioned on your
side, the working lights stay off.
2. When moving the working-light-switch to the first
position, the front working light turns on.
3. When moving the working-light-switch to the
second position, both the front working light and the
rear working light turn on.
INSTRUMENT PANEL AND SWITCH SWITCHES
