Kubota SVL65-2 User Manual

2.3 How to use the armrest
1. Move
the armrests to the raised position to lock out
the hydraulic and electric systems.
(1) Armrest (A) Raise
NOTE :
• When
the armrests are moved to the raised
position, the parking brake will engage and
the hydraulic and operation system will be
locked.
Move the armrests to the lowered position
and push the hydraulic-unlock-switch in
order to activate the hydraulic controls.
• When you start the engine, disengage the
hydraulic lock so that the hydraulic controls
are activated.
If the armrests are raised and then lowered
during the operation, you must disengage
the hydraulic lock so that the hydraulic
controls are activated.
3. Driving
WARNING
T
o avoid personal injury or death:
• Before starting the engine, make sure that no
one is near the machine.
3.1 Traveling forward and backward
To move forward
1.
Push the left-control-lever (traveling lever) forward.
(1) Left control lever (traveling
lever)
(A) Push
(B)
Forward
To move backward
1.
Pull the left-control-lever (traveling lever) backward.
OPERATION OPERATION OF THE MACHINE
58
SVL65-2

Kubota SVL65-2 Specifications

General

Rated Operating Capacity	2, 100 lbs
Travel Speed	7.1 mph
Travel Speed, High	7.1 mph
Hydraulic System Flow	17.4 gpm
Lift Arm Breakout Force	6, 834 lbs (3, 100 kg)
Net Power	74 hp (55.2 kW)
Overall Length (with bucket)	157.5 in (4, 000 mm)
Height to Top of Cab	82 inches
Overall Length	157.5 in (4, 000 mm)
Overall Width	72 in (1, 830 mm)
Overall Height	82 inches
