Kubota WSM F2880 User Manual

2-S5
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
TRANSMISSION
(Continued)
W1027629
Item Factory Specification Allowable Limit
Differential Pinion Shaft to Differential
Pinion
Differential Pinion
Differential Pinion Shaft
Clearance
I.D.
O.D.
0.016 to 0.045 mm
0.0007 to 0.0018 in.
16.000 to 16.018 mm
0.6300 to 0.6306 in.
15.973 to 15.984 mm
0.6289 to 0.6292 in.
0.30 mm
0.0118 in.
–
–
Differential Pinion to Differential Side Gear Backlash 0.1 to 0.3 mm
0.004 to 0.011 in.
0.4 mm
0.016 in.
Bevel Pinion Shaft Side Clearance Less than 0.15 mm
Less than 0.006 in.
–
Bevel Pinion Shaft to Spiral Bevel Gear Backlash 0.10 to 0.30 mm
0.0040 to 0.0118 in.
–
