2-S28
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
TRANSMISSION
Differential Side Gear and Differential Pinion
1. Put parting marks on the differential pinion (2) and the differential
side gear (1).
2. Tap out the dowel pin (3).
3. Remove the differential pinion shaft.
4. Remove the differential pinion (4), differential side gear (1) and
shim (5).
(When reassembling)
• Install the differential pinion and differential side gear, aligning
the parting marks.
W1027910
(1) Differential Side Gear
(2) Differential Pinion
(3) Dowel Pin
(4) Differential Pinion
(5) Shim
To Next Page
