8-S5
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
ELECTRICAL SYSTEM
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-8)
W1012736
Item N·m kgf·m ft-lbs
Starter B terminal nut 7.8 to 9.8 0.8 to 1.0 5.8 to 7.2
Starter C terminal nut 7.9 to 11.8 0.8 to 1.2 5.8 to 8.7
Starter Magnetic switch mounting nut 5.9 to 10.8 0.6 to 1.1 4.4 to 7.9
Starter Through bolt 4.42 to 7.35 0.45 to 0.75 3.23 to 5.42
Alternator Pulley nut 58.3 to 78.9 5.95 to 8.05 43.0 to 58.2
To Next Page
