1-S5
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
ENGINE
ENGINE BODY (Continued)
W1013874
Item Factory Specification Allowable Limit
Rocker Arm Shaft to Rocker Arm
Rocker Arm Shaft
Rocker Arm
Clearance
O.D.
I.D.
0.016 to 0.045 mm
0.00063 to 0.00177 in.
11.973 to 11.984 mm
0.4714 to 0.4718 in.
12.000 to 12.018 mm
0.4724 to 0.4731 in.
0.10 mm
0.0039 in.
–
–
Push Rod Alignment – 0.25 mm
0.0098 in.
Tappet to Tappet Guide
Tappet
Tappet Guide
Clearance
O.D.
I.D.
0.020 to 0.062 mm
0.0008 to 0.0024 in.
19.959 to 19.980 mm
0.7858 to 0.7866 in.
20.000 to 20.021 mm
0.7874 to 0.7882 in.
0.07 mm
0.0028 in.
–
–
Timing Gear
Crank Gear to Idle Gear 1
Idle Gear 1 to Cam Gear
Idle Gear 1 to Injection Pump Gear
Backlash
Backlash
Backlash
0.032 to 0.115 mm
0.0013 to 0.0045 in.
0.036 to 0.114 mm
0.0014 to 0.0045 in.
0.034 to 0.116 mm
0.0013 to 0.0046 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
Governor Gear
Governor Gear to Injection Pump
Gear
Backlash 0.030 to 0.117 mm
0.0012 to 0.0046 in.
0.15 mm
0.0059 in.
KiSC issued 04, 2006 A
