Kubota WSM L3560 User Manual

ENGINE
L3560, L4060, L4760, L5060, L5460, L6060, WSM
1-S9
COOLING SYSTEM
9Y1210824ENS0002US0
Item Factory Specification Allowable Limit
Fan Belt Tension 7.0 to 9.0 mm (0.28 to
0.35 in.) deflection at
98 N (10 kgf, 22 lbf) of
force
–
Thermostat Valve Opening-
Temperature
(When the valve
starts to open)
Opening-
Temperature
(When the valve
opened
completely)
80.5 to 83.5 °C
176.9 to 182.3 °F
95 °C
203 °F
–
–
Radiator Water Tightness No leak at
specified pressure
–
Radiator Cap Pressure
Decreasing Time
More than 10 seconds
for pressure decrease
from 90 to 60 kPa
from 0.9 to 0.6 kgf/cm
2
from 10 to 9 psi
–
KiSC issued 03, 2016 A

Kubota WSM L3560 Specifications

General

Type	Compact Utility Tractor
Engine Model	Kubota V1505-T
Horsepower	37 hp (27.6 kW)
Fuel Type	Diesel
Drive	4WD
Hydraulic System	Open center
3-Point Hitch	Category I
PTO Horsepower	30.5 hp (22.7 kW)
Transmission	Hydrostatic
Number of Gears	3-range
Height	91.3 in (232 cm)
Tire Size (Front)	7-16
Tire Size (Rear)	15-19.5
Displacement	91.4 cu. in. (1, 499 cc)
