BRAKES
L3560, L4060, L4760, L5060, L5460, L6060, WSM
5-S3
3. TIGHTENING TORQUES
Tightening torques of screws and nuts in the table below are especially specified.
(For general use screws and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.)
9Y1210824BRS0003US0
Item N·m kgf·m lbf·ft
Rear wheel mounting screw and nut 197 to 225 20.0 to 23.0 145 to 166
ROPS lower frame mounting screw 167 to 196 17.0 to 20.0 123 to 144
Cabin mounting bolt and nut 124 to 147 12.6 to 15.0 91.5 to 108
Cabin mount bracket mounting screw (7T) 124 to 147 12.6 to 15.0 91.5 to 108
Cabin mount bracket mounting screw (9T) 167 to 196 17.0 to 20.0 123 to 144
Rear axle case mounting screw (M10) 48 to 55 4.9 to 5.7 36 to 41
Rear axle case mounting nut (M10, 9T) 61 to 70 6.2 to 7.2 45 to 52
Rear axle case mounting screw (M12) 78 to 90 7.9 to 9.2 58 to 66
Brake case mounting screw and nut 78 to 90 7.9 to 9.2 58 to 66
Floor seat mounting bolt and nut 200 to 220 20 to 23 150 to 160
Fulcrum screw (Manual tranmission and GST) 40 to 44 4.0 to 4.5 29 to 32
Fulcrum screw (HST) 63 to 72 6.4 to 7.4 47 to 53
Brake cam lever mounting nut 63 to 72 6.4 to 7.4 47 to 53
KiSC issued 03, 2016 A

Kubota WSM L3560 Specifications

General

Type	Compact Utility Tractor
Engine Model	Kubota V1505-T
Horsepower	37 hp (27.6 kW)
Fuel Type	Diesel
Drive	4WD
Hydraulic System	Open center
3-Point Hitch	Category I
PTO Horsepower	30.5 hp (22.7 kW)
Transmission	Hydrostatic
Number of Gears	3-range
Height	91.3 in (232 cm)
Tire Size (Front)	7-16
Tire Size (Rear)	15-19.5
Displacement	91.4 cu. in. (1, 499 cc)
